⚙️ Principais recursos
Fast QR Code Ticketing — Visitors can scan booking codes or pay on-site for instant ticket printing.
Large 32-Inch Touch Screen — 10-point capacitive touch, bright 1080p display for clear guidance even under sunlight.
Leitor de cartão integrado — Suporta NFC, EU IA, or membership card recognition for tourist management systems.
Impressão térmica de alta velocidade — 80mm receipt printer delivers tickets or payment slips within seconds.
Windows-Based System — Compatible with multiple ticketing and management software platforms.
Durable and Secure Structure — Anti-rust metal casing with waterproof, dustproof, and anti-static coating for outdoor deployment.
Optional Face Recognition Camera — Enables smart identity verification and visitor analytics.
🧩 Especificações Técnicas
| Papel | Nome | Parâmetros de acessórios |
|---|---|---|
| Gabinete | Concha de chapa metálica | High-quality cold-rolled steel, anti-rust and anti-corrosion coating, impermeável, dustproof, à prova de óleo, and anti-static; equipped with independent ventilation system. |
| Módulo de controle principal | Placa-mãe de controle industrial | Intel i5 series CPU, 10 portas seriais, LAN Gigabit, LVDS/HDMI output. |
| Memória | 4GB DDR3 | |
| Disco rígido | 128SSD de GB | |
| Sistema | Windows 7 Professional 64-bit | |
| Módulo de exibição de toque | Tela LCD | 32-polegadas LCD, 16:9 proporção, 1920Resolução ×1080, 350brilho cd/m² |
| Tela sensível ao toque | 32-inch 10-point capacitive touch, 7Dureza H, >85% transmitância de luz, Interface USB | |
| Módulo de entrada | Leitor de cartão | ISO/IEC 14443 Type A/B compliant, reading distance 0–3cm, Interface USB |
| Leitor de código QR | Supports 1D/2D code reading for ticket or payment verification | |
| Câmera | 200W HD binocular camera for face recognition and photography (opcional) | |
| Módulo de saída | Impressora de recibos | 80impressora térmica mm, 150velocidade de impressão em mm/s, USB connection |
| Power Module | Power strip | Input voltage: CA100–240V; output: 12V/24V |
🏞️ Cenários de aplicação
🎟️ Pontos panorâmicos & Atrações turísticas — Ticket collection, pagamento, e reimpressão.
🏛️ Museus & Parks — Self-check-in, membership verification, and QR scanning.
🚉 Centros de Transporte — Boarding pass retrieval or tourist pass payment.
🎡 Parques Temáticos & Estâncias — Smart entry with QR or NFC scanning.
