⚙️ Principais recursos
Ultra-Large 55-Inch Touch Display — Full HD resolution with high brightness for clear visibility and user-friendly navigation.
Optional 10.1-Inch Fair Scale Display — Displays real-time weight information for produce or bulk goods, enabling transparent transactions.
High-Speed Scanning — Integrated 1D/2D barcode scanner with wide viewing angle for fast product recognition.
Built-In Thermal Printer — 80mm auto-cut printer for receipts, invoices, or promotional coupons.
Modular Cabinet Design — All-steel structure with ergonomic layout, front-open maintenance, and pull-out track system.
Powerful Industrial PC — Equipped with Intel i5 processor, 8GB RAM, and 256GB SSD ensuring stable and smooth operation.
Flexible Payment Options — Supports card, QR, NFC, and POS payment interfaces.
Stable and Secure Operation — Anti-tamper design, overcurrent protection, and anti-blocking functions ensure safe and long-term use.
Customizable Hardware — Options for stainless steel shell, additional screens, and software integration with POS systems.
🧩 Especificações Técnicas
| Parâmetro | Especificação |
|---|---|
| Modelo | Self-Checkout Kiosk |
| Mostrar | 55-inch LCD Touchscreen, 1920×1080, brightness ≥350 cd/m², 10-ponto de toque capacitivo |
| Optional Display | 10.1-inch LCD on fair scale (1920×1200) |
| Cabinet Material | Aço laminado a frio, 1.5mm thickness, front-open or lift-door maintenance |
| Processador | Intel i5 (4th Gen) |
| Motherboard | Intel® H81 chipset, supports Pentium/Celeron/i3/i5/i7 |
| Memória | 8GB DDR3 |
| Armazenar | 256SSD de GB |
| Fonte de energia | 300W Industrial Power Module |
| Leitor de código de barras | 1D/2D code recognition, wide-angle LED illumination |
| Impressora | 80impressora térmica mm, 150mm/s printing speed, auto cutter |
| Weighing Scale (Optional) | Range: 0–100kg, Sensor Type: Digital, Interface: USB/UART |
| PDV / Payment Module | External POS terminal, QR & NFC supported |
| Operating Voltage | 12V DC |
| Conectividade | Ethernet, USB, RS232 |
| System Platform | Windows 10 / Android 11 opcional |
| Material & Finish | All-steel structure, anti-rust, anti-corrosion powder coating |
| Maintenance | Pull-out track for modules, easy service access |
| Opções de cores | Branco, Gray, or Custom corporate color |
| Embalagem | PE foam + wooden crate |
🏪 Cenários de aplicação
Supermercados & Grocery Stores: Self-checkout for groceries, produce weighing, and contactless payment.
Retail Chains & Convenience Stores: Fast checkout and receipt printing.
Cafeterias & Quick-Service Restaurants: Ordem, weigh, and pay seamlessly at one terminal.
Smart Retail & Vending Hubs: Suitable for unmanned stores and automated kiosks.
Farmácias & Department Stores: Simplify payment and reduce cashier workload.
