⚙️ Principais recursos
Secure Cash Deposit & Dispensing — Integrated cash acceptor supports counterfeit detection and optional recycling module for both deposit and payout.
Card Payment Support — Compatible with magnetic stripe, IC chip, and contactless cards (NFC/EMV).
High-Speed Thermal Printer — Prints payment receipts, contas, and reports with precision and durability.
Interface amigável — Industrial-grade touchscreen display provides an intuitive and guided user experience.
Network Connectivity — Supports Ethernet and optional 4G wireless communication for remote operation and monitoring.
Data Security — Encrypted transactions, tamper detection, and secure cash box ensure safety during all operations.
Easy Maintenance — Modular design with front access to printer, cash cassette, and motherboard for quick service.
Durable Structure — Made from cold-rolled steel with powder-coated finish for corrosion resistance and long-term use.
🧩 Especificações Técnicas
| Parâmetro | Especificação |
|---|---|
| Modelo | XTD-8011 Payment ATM |
| Function | Cash deposit / cancelamento / payment processing |
| Cabinet Material | Cold-rolled steel with anti-corrosion powder coating |
| Mostrar | Industrial touchscreen display (size optional) |
| Aceitante de dinheiro | Bill validator with counterfeit detection, 3000-note capacity |
| Reciclador / Distribuidor | Optional module for cash payout and recycling |
| Leitor de cartão | Magnetic stripe / CI / NFC / EMV card support |
| Impressora | 80impressora térmica mm, automatic cutting, high-speed printing |
| Leitor de código de barras | 1D/2D scanner for QR code or ticket scanning (opcional) |
| System Platform | Android / Windows (configurable) |
| Processador | RK series / Intel i3-i5 (opcional) |
| Memória & Armazenar | 4GB RAM / 64–128GB SSD |
| Comunicação | Ethernet standard, optional 4G or Wi-Fi |
| Fonte de energia | AC 100–240V 50/60Hz |
| Consumo de energia | ≤150W (depends on configuration) |
| Segurança | Tamper alarm, key lock, and encrypted data transmission |
| Operating Environment | 0°C – 45°C, 10–90% RH (non-condensing) |
| Certificação | CE / FCC / RoHS (opcional) |
🏦 Application Scenarios
Bancário & Microfinance Institutions: Cash deposit, account top-up, and card transaction automation.
Government Payment Stations: Pagamento de contas de serviços públicos, fine collection, and tax services.
Varejo & Supermarket Chains: Customer cash payments, balance check, and voucher redemption.
Transporte & Parking Hubs: Ticket payment, fare top-up, and automatic receipt printing.
Corporate Facilities: Employee salary collection or reimbursement terminals.
Instalação & Maintenance Notes
- Requires stable AC power and wired network (Ethernet); optional 4G for remote sites.
- Place on a level, secured floor or countertop as recommended by the manual; ensure rear and side clearances for maintenance.
- Cash boxes and recycler modules are front-access; regular scheduled emptying and audit procedures are recommended.
- Follow the manual for firmware update procedure, receipt paper replacement, and emergency cash jam handling.
