⚙️ Ключевые особенности
Android 11 Операционная система — Fast, stable, and compatible with various ticketing and payment apps.
32-Inch HD Capacitive Screen — Full HD 1080p display with anti-glare coating and 10-point touch.
Dual QR Code Scanners — Supports two-way QR recognition for both user and staff sides, improving throughput efficiency.
Integrated Card Reader — Reads IC/ID and NFC cards for member verification or access control.
Thermal Ticket Printer — 80mm high-speed receipt printer for ticket and payment slip output.
High Brightness Display — 350cd/m² brightness ensures visibility under strong light.
Durable Construction — Cold-rolled steel cabinet with powder-coated anti-rust finish and internal ventilation.
Modular Expansion — Optional camera, 4G Модуль, and secondary 10.1-inch display for dynamic advertisement or map display.
🧩 Технические характеристики
| Часть | Имя | Accessory Parameters |
|---|---|---|
| Шкаф | Корпус из листового металла | High-strength cold-rolled steel frame with anti-corrosion and waterproof coating; internal ventilation and cable management system. |
| Main Control Module | Материнская плата промышленного управления | RK3568 quad-core processor, Mali-G52 GPU, 2GB DDR4 memory, 16GB eMMC storage. |
| Система | Android 11.0 | Supports OTA update, multi-language UI, and app integration. |
| Отображение модуля | LCD Screen | 32-дюймовый ЖК-дисплей, 1920×1080 разрешение, 350кд/м² яркость, 16:9 aspect ratio. |
| Touch Screen | 10-point capacitive, >85% transmittance, USB-интерфейс. | |
| Input Module | Сканер QR-кода | Dual 1D/2D scanner setup for quick access validation. |
| Card Reader | IC/ID/NFC card reading, ISO/IEC 14443 Type A/B standard. | |
| Output Module | Чековый принтер | 80мм термопринтер, 150скорость мм/с, auto cutter. |
| Камера (Необязательный) | 2MP or 5MP | For face recognition and data capture. |
| Источник питания | 12V/24V | AC100–240V input, integrated surge protection. |
| Сеть | Wi-Fi, Ethernet, 4Глин (необязательный) | Stable connection for real-time verification. |
| Материал | Холоднокатаная сталь | Powder coating, rust-proof and anti-fingerprint surface. |
| Package | — | Foam + wooden box for secure transport. |
🏞️ Application Scenarios
🎟️ Tourist Attractions: On-site ticket purchase, QR scanning, and entry verification.
🚉 Transport Terminals: Ticket check-in and card-based travel authorization.
🏖️ Theme Parks: Self-service entry, group ticket validation, and reprinting.
🏢 Visitor Centers: Tourist information inquiry, route guidance, and booking.
