⚙️ Main Features
-
32-inch Full HD Display – 1920×1080 resolution with BOE A-grade panel, 350–400 nits brightness.
-
Full Black Design – Elegant appearance, Pantone color customization available.
-
Integrated Printer – Built-in 80mm thermal printer for fast and quiet receipt printing.
-
QR-код & Сканер штрих -кода – High-speed scanning performance for payment and verification.
-
НФК & Credit Card Payment – Support for contactless and bank card transactions.
-
POS Integration – Space reserved for customer’s own POS terminal.
-
Optional Safety Add-ons – Air circuit breaker, leakage protection switch, and timer for auto power control.
-
System Options – Android 7.1 / 11 or Windows 7 / 10 Pro as per software requirement.
-
Mounting Options – Wall-mounted, floor-standing, or fixed installation with screws.
-
Certified Quality – Passed CE, ФКС, and RoHS certifications.
📊 Specification
| Категория | Описание |
|---|---|
| Screen Size | 32-дюйм |
| Разрешение | 1920×1080 (Полное HD) |
| Display Area | 698×392 mm |
| Яркость | 400 кд/м² |
| Контрастность | 1200:1 |
| Угол обзора | 178°/178° (H/V) |
| Response Time | 8 ms |
| Touch Type | 10-point PCAP capacitive touch |
| Lifetime | >50,000 hours |
| Материал | Aluminum + Metal |
| Варианты цвета | Full Black / Белый (Customizable) |
| Принтер | Built-in thermal printer, 80mm width |
| Сканер QR-кода | Встроенный, supports 1D/2D barcodes |
| Источник питания | AC 110V–240V, 50/60Гц |
| Power Consumption | 80W. |
| Рабочая температура | 0°С–50°С |
| Температура хранения | −20°C–60°C |
| Сертификаты | CE / ФКС / РоХС |
💻 System Configuration
| System Type | Windows Version | Android Version |
|---|---|---|
| Процессор | Intel® i3 / я5 / i7 | RK3288 Quad-core Cortex-A17 1.8GHz |
| БАРАН | 4ГБ DDR3 | 2ГБ DDR3 |
| Хранилище | 128ГБ SSD | 8GB eMMC |
| ОС | Окна 7 / 10 Pro | Android 7.1 with Google Play |
| Сеть | LAN / Wi-Fi | LAN / Wi-Fi |
| Интерфейсы | HDMI out ×1, USB ×4, LAN ×1, VGA ×1 |
🏪 Application Scenarios
-
🍔 Restaurants & Fast Food Stores – Self-ordering and cashless payment.
-
🎬 Cinemas & Universities – Compact design for high-traffic self-service zones.
-
⛽ Gas Stations & Convenience Stores – Secure and efficient unattended payment terminal.
-
🛍️ Shopping Malls & Food Courts – Multi-payment kiosk to reduce queue time.
