⚙️ Principais recursos
🍔 Interactive 21.5-Inch Touch Screen
Full HD 21.5-inch LCD display (1920×1080) com 10-ponto de toque capacitivo.
High brightness and anti-glare surface ensure excellent visibility in indoor light.
Responsive interface designed for intuitive ordering and customer engagement.
💳 All-in-One Multi Payment System
Leitor NFC: Supports contactless payments such as Apple Pay, Google Pay, and UnionPay QuickPass.
Bankcard Reader: Secure chip or swipe card transactions for debit and credit cards.
Leitor de tarja magnética: Reads traditional payment and loyalty cards.
IC Card Reader: Supports smart cards and membership identification.
Leitor de código QR: Reads all 1D and 2D codes for Alipay, Pagamento WeChat, or e-vouchers.
Teclado PIN: Encrypted input for secure transactions and privacy protection.
📄 Impressão & Receipts
Embutido impressora térmica de alta velocidade for immediate printing of receipts, order slips, or invoices.
Supports black mark recognition and automatic paper cutting.
👁️ Smart Sensing & Segurança
Câmera Integrada: Enables face detection or visual communication functions.
Sensor de corpo humano: Automatically activates screen when users approach to save power.
Data Encryption: Ensures financial-grade transaction security and customer privacy.
🔗 Conectividade & Integração
Compatível com PDV, ERP, or restaurant management systems.
Wi-fi, Ethernet, or optional 4G module for flexible network connectivity.
Suporta Android ou Windows operating systems for software customization.
🧩 Design durável
Constructed with cold-rolled steel and tempered glass, built for continuous operation.
Modular structure for quick maintenance, atualizações, and branding customization.
Ideal for wall-mounting or floor-stand installation.
🧰 Especificações Técnicas
| Componente | Especificação |
|---|---|
| Mostrar | 21.5-polegadas LCD, 1920×1080, 16:9 proporção |
| Tela sensível ao toque | 10-ponto capacitivo, transmitância >85% |
| CPU / Sistema | Android 11 / Windows 10 opcional |
| Módulos de Pagamento | NFC, Cartão IC, bank card, magnetic stripe card, Leitor QR, PIN pad |
| Câmera | HD camera for face or payment capture |
| Impressora de recibos | 80mm panel thermal printer, auto-cutting |
| Sensor | Infrared human body sensor |
| Conectividade | Wi-fi / Ethernet / Optional 4G |
| Material | Aço laminado a frio com revestimento em pó |
| Instalação | Wall-mounted or floor stand |
| Fonte de energia | CA 100–240 V, 50/60Hz |
🏢 Cenários de aplicação
🍱 Restaurantes & Cafeterias: Quick ordering, navegação no menu, and self-payment.
☕ Cafés & Lojas de sobremesas: Card, QR, or NFC contactless checkout.
🛒 Varejo & Supermercados: Multi-payment counter for seamless transactions.
🏫 Campus & Cantinas: ID card-based or QR-based meal pickup.
🏢 Edifícios Corporativos: Employee self-ordering and automated canteen systems.
