🖥️ Flexible Screen Options
Available in 21.5 to 32 inches, with 1920×1080 Full HD resolution, offering sharp, vibrant, and clear visuals for digital menus and promotional displays.
⚡ Powerful Performance
Equipped with Intel J1900 / i3 / i5 / i7 or RK3288 / RK3399 chipsets for Windows and Android platforms, ensuring smooth user experience and reliable multitasking.
👆 Responsive Capacitive Touch
10-point capacitive touch technology with over 80,000 hours lifespan provides precise, fast, and durable operation for interactive ordering.
💳 Multiple Payment Methods
Supports QR/barcode scanner, NFC card reader, and POS holder for cashless transactions including mobile payments, e-wallets, and membership cards.
📶 Comprehensive Connectivity
Built-in LAN, Wi-Fi, 4G, and VPN support keeps the kiosk connected at all times, suitable for busy environments such as restaurants, malls, and airports.
🔊 Integrated Components
Comes with 58mm/80mm thermal receipt printer, facial recognition binocular camera, and stereo speakers, providing an all-in-one ordering experience.
🧱 Flexible Installation
Available as wall-mounted or floor-standing, easily adaptable to restaurant counters, self-ordering zones, or drive-through areas.
🧩 Technical Specifications
| Item | Specification |
|---|---|
| Size | 21.5–32 inch |
| Resolution | 1920×1080 Full HD |
| Touch Type | Capacitive touch |
| Touch Points | 10 points |
| Touch Life | >80,000 hours |
| Operating System | Android / Windows |
| CPU (Windows) | Intel J1900 / i3 / i5 / i7 |
| CPU (Android) | RK3128 / RK3368 / RK3288 / RK3399 |
| Graphics Card | Intel HD / Android HD |
| RAM (Windows) | 2G / 4G / 8G / 16G / 32G |
| RAM (Android) | 2G / 4G |
| Storage | SSD 64G / 128G / 256G or TF 8G / 16G / 32G / 64G |
| Network | LAN / Wi-Fi / 4G / VPN |
| Interfaces | DC×1, RJ45×1, HDMI×1, WiFi×1, USB2.0×1, MIC×1 |
| Power Input | AC 110–220V, 50/60Hz |
| Power Consumption | 110W (≤3W standby) |
| Installation | Wall-mounted / Floor-standing |
| Display Brightness | 350 cd/m² |
| Viewing Angle | 178° (H/V) |
| Service Life | ≥50,000 hours |
| Operating Temperature | -10°C ~ 50°C |
| Storage Temperature | -25°C ~ 60°C |
🏪 Application Scenarios
-
🍟 Fast Food Restaurants: Self-service ordering and cashless payment for quick checkout.
-
🏬 Shopping Malls: Digital food court ordering or interactive product displays.
-
⛽ Gas Stations & Parking Lots: Mobile recharge and ticket payment.
-
🏨 Hotels & Cafés: Customer self-check-in and ordering terminals.
-
🚉 Stations & Airports: Automated ordering and service inquiry kiosks.
